eTM-UMM-6 Modular Rack Multi-Channel DC Power Supply System (6-Channel 19-inch)
Need this configuration?
Request a Quote for eTM-UMM-6
Request a Quote for eTM-UMM-6
Modular 19-inch rack DC power system with up to six independently controlled channels, 15–100 V module options, RS232/RS485/USB and protection functions.
Description
Technical Specifications
Technical Specifications
| System Chassis | eTM-UMM-6 (19-inch Rackmount) |
|---|---|
| Max Output Channels | 6 Independent Modular Channels |
| Total System Power | Up to 6000W Combined Output |
| Configurable Modules | 15V/60A (900W), 20V/50A (1000W), 30V/20A (600W), 30V/30A (900W), 50V/20A (1000W), 60V/10A (600W), 60V/15A (900W), 60V/20A (1200W), 100V/5A (500W), 100V/10A (1000W) |
| Communication | RS232, RS485, USB Standard Interface |
| Chassis Dimensions | 500(D) × 430(W) × 155(H) mm | Approx. 18.7 kg |
Product Overview
Product Overview
UMM-6 is a modular 19-inch rack-mounted DC power system for multi-rail ATE, semiconductor burn-in, production validation and laboratory automation. Each channel is controlled independently and the module mix is selected for the actual voltage, current and power required by the test.
Module configuration
| Module | Output | Power |
|---|---|---|
| L | 0–15 V / 0–60 A | 900 W |
| M | 0–20 V / 0–50 A | 1000 W |
| N | 0–30 V / 0–20 A | 600 W |
| O | 0–30 V / 0–30 A | 900 W |
| P | 0–50 V / 0–20 A | 1000 W |
| Q | 0–60 V / 0–10 A | 600 W |
| R | 0–60 V / 0–15 A | 900 W |
| S | 0–60 V / 0–20 A | 1200 W |
| T | 0–100 V / 0–5 A | 500 W |
| U | 0–100 V / 0–10 A | 1000 W |
How to choose
- List the voltage and current required by each test channel.
- Select a module that covers the operating point and power limit.
- Confirm channel count, rack wiring, communication protocol and input configuration.
- Send the module combination and destination with your Request a Quote.
Applications
- Battery and energy-storage test fixtures
- Semiconductor burn-in and aging
- Production-line validation
- Multi-channel R&D benches
FAQ
▶ Can channels use different modules?
Yes. The system is designed for a selected mix of module options, subject to the final power and wiring check.
▶ Are channels independently controlled?
Yes. Each channel can control its own output parameters and status.
▶ Is AC 110 V standard?
Do not assume it. Confirm the input configuration for the exact system in the quotation.
▶ What should I include in an inquiry?
Include channel count, voltage/current per channel, module letters, interface and destination.
