eTM-SM6005FT 4-Channel Stepper Motor Driver Power Supply 60V 5A Adjustable
Need this configuration?
Request a Quote for eTM-SM6005FT
Request a Quote for eTM-SM6005FT
Four-channel 60 V/5 A stepper motor driver test power supply with adjustable frequency, pulse count, CW/CCW control and alarm thresholds.
Description
Technical Specifications
Technical Specifications
| Model | eTM-SM6005FT |
|---|---|
| Output Channels | 4 Independent Channels |
| Voltage / Current | DC 60V / 5A Total |
| Frequency Range | 30Hz ~ 9999Hz Adjustable (±0.05%+0.1Hz) |
| Pulse Count Setting | 0 ~ 65,000 Pulses (1 pulse/step) |
| Beat Modes | 2-2 beats, 1-2 beats, 1-1 beats, Single Step, Continuous |
| Steering & Control | Forward (CW) / Reverse (CCW), External Trigger, Touch/Button |
Product Overview
Product Overview
eTM-SM6005FT is a four-channel stepper motor driver test power supply for repeatable driver evaluation and automated fixtures.
Confirmed specifications
| Item | Specification |
|---|---|
| Output | DC 60 V / 5 A |
| Channels | 4; total channel current must remain within the rated limit |
| Frequency | 30 Hz–9999 Hz adjustable |
| Pulse count | 0–65,000 |
| Modes | Single step, continuous, set number and count |
| Direction | CW and CCW |
How to choose
Choose the four-channel version when the fixture needs several driver channels without the density of an eight-channel rack. Confirm wiring, total current, frequency and start/stop control.
Applications
- Stepper motor driver validation
- Forward/reverse sequence tests
- Four-channel production fixtures
- Pulse and frequency testing
FAQ
▶ Can all four channels run at maximum rating together?
Total output current must remain within the power supply’s maximum rated output. Confirm the test profile before ordering.
▶ How are tests started and stopped?
Touch-screen, button and external-trigger start/stop methods are listed in the specification.
