eTM-E150A Programmable DC Electronic Load 150W 150V 30A, CC/CV/CR/CP Modes

See the Product Overview and Technical Specifications sections above for confirmed specifications, applications, selection guidance and FAQs.

Technical Specifications

Model	eTM-E150A
Rated Power	150W Maximum Continuous
Voltage Range	0 ~ 15V / 0 ~ 150V (Dual Range)
Current Range	0 ~ 3A / 0 ~ 30A
Modes	CV, CC, CR (0.001Ω–10kΩ), CP
Accuracy	Voltage: ±(0.05%+0.025%FS) | Current: ±(0.05%+0.05%FS)
Dimensions / Weight	255 × 80 × 155 mm | 2.45 kg

Product Overview

eTM-E150A is a programmable single-channel DC electronic load for controlled discharge, power-supply verification, burn-in and laboratory testing.

Confirmed specifications

Item	Confirmed range
Maximum power	150 W
Voltage range	0–15 V or 0–150 V
Current range	0–3 A or 0–30 A
Constant resistance	0.001 Ω–10 kΩ
Modes	CV, CC, CR and CP

How to choose

Start with the maximum test voltage and current, then check the 150 W power limit. Use CV for voltage-clamped tests, CC for fixed-current discharge, CR for resistance emulation and CP for constant-power profiles.

Applications

• Battery discharge and capacity checks
• DC supply burn-in and verification
• Dynamic or repeatable load testing
• Laboratory power electronics testing

FAQ

▶ Does 150 V and 30 A mean 4500 W simultaneously?

No. The unit is rated at 150 W; voltage, current and power must remain within the permitted operating envelope.

▶ Which mode should I use for battery testing?

Use CC for a fixed-current discharge, CP for a constant-power profile, or CR for resistance emulation.

▶ Can the load be controlled remotely?

Confirm the required interface and command set for the exact configuration before ordering.
